Product properties:
Electrical properties
LC：≤0.10µA/cm2
Formation condition：
Formation liquid: 0.1%H3PO4
Formation temperature: 90±2
Density of the frmation Current: 5mA/cm2
Formation voltage/time: 225V/30min
Product properties:
1. Electrical properties
LC：≤0.10µA/cm2
Formation condition：
Formation liquid: 0.1%H3PO4
Formation temperature: 90±2
Density of the frmation Current: 5mA/cm2
Formation voltage/time: 225V/30min
Spec. diameter tolerance allowed
| Specification mm |
Diameter tolerance allowed mm |
|
0.10mm~0.15mm |
±0.005 |
|
>0.15mm~0.30mm |
±0.006 |
|
>0.30mm |
±0.007 |
Mechanical properties
| Product condition |
Tensile strength Mpa |
Elongation % |
|
Annealled |
300~600 |
10~30 |
|
Half annealed |
>600~1000 |
<5 |
|
Unannealled |
>1000 |
<5 |
Product properties:
1. Electrical properties
LC：≤0.10µA/cm2
Formation condition：
Formation liquid: 0.1%H3PO4
Formation temperature: 90±2
Density of the frmation Current: 5mA/cm2
Formation voltage/time: 225V/30min
